Embedded SBCs for Automation & Control: small, fast, tons of I/O & Software Support


Tiny, fast, resources for Linux and I/O to burn

WildFireMod - tiny, fast, with resources for Linux

Ethernet ColdFire MCF5282 Module adds smarts, memory, connectivity and I/O to custom relay/sensor boards.

  • 55 digital IO and 8 Analog Inputs to handle large applications
  • Plugs into custom boards through std. HD connectors
  • SBCTools, Eclipse Edition - Integrated Development Toolset
  • Easy to use Real Time Library & demos speed development
  • SD Card socket (up to 2GB storage, etc.)
  • 10/100 Ethernet, 3 RS232 Serial & 1 CAN port, w. drivers
  • Real time battery backed clock calendar
  • Tiny form factor: only 44mm x 49mm
  • And many more features...

SBCTools - Software Development Tools and Linux Preconfigured for Embedded Controllers

SBCTools-uClinux - Software Development Tools and Linux Preconfigured for Embedded Controllers

Integrated development environment (IDE) with board support packages (BSP) offers productivity enhancing features.

  • uClinux preconfigured to target microcontroller
  • Create uClinux exacutables and archives
  • C library provided by uClibc, includes multithreading support
  • Easy to use Real Time Library & demos speed development
  • Compiler runs as native windows application (no cygwin)
  • Fast TCP/IP debugging with GDBServer
  • All seamlessly integarted under an Eclipse IDE
  • And many more features...


Small Microcontroller Boards

Tiny, fast, resources for Linux and I/O to burnWildFire5282 - Ethernet ColdFire MCF5282 SBC with tons of of I/O

Linux capable Eternet ColdFire MCF5282 SBC offers unbeatable value in features and abundance of I/O.

  • 57 digital IO and 8 Analog Inputs to handle large applications
  • I/O pins connect to ribbon cables. No carrier board required
  • SBCTools, Eclipse Edition - Integrated Development Toolset
  • Easy to use Real Time Library & demos speed development
  • SD Card socket (up to 1GB storage, WiFi, etc.)
  • 10/100 Ethernet, 3 RS232 Serial Ports and 1 CAN port
  • Battery Backed Clock Calendar for zero power Hibernation
  • And many more features...

M5208EVB - Evaluation Board/Reference Design preloaded with uClinux

Showcases the fast low power Coldfire MCF5208 MCU accessing massive amouts of memory.

  • 166MHz ColdFire MCF5208
  • 32MB fast, low power DDR SDRAM
  • Very low power MCU < 260mw, < 1.67mw/MIP
  • 10/100 BaseT Ethernet and 2 RS232 Serial ports
  • ZigBee capable transceiver
  • Powerful development tools including CodeWarrior and SBCTools
  • Ships preloaded with uClinux
  • ..and more...

Steroid Stomp 555 - embedded PowerPC with tons of I/O

Microcontroller with Power, features and an abundance of sohisticated I/O in a small form factor. Ideal for demanding aerospace and defence type of applications.

  • 40MHz MPC555 embedded RISC PowerPC with Floating Point Unit
  • 32 analog inputs with 10 bit resolution, highly programmable
  • 32 highly programmable TPU (Time Processing Unit) channels
  • 8 PWM channels plus 16 fast dual action (start/stop) timer channels
  • 578K SRAM, 448K Flash, 2 serial ports and 2 CAN ports
  • And many more features...

Mite v3 - fast, affordable, tons of I/O

Ideal SBC for electric and internal combustion motor control, robotics, industrial automation, building control, data acquisition, instrumentation...

  • 25.1MHz Motorla 68HC16Z1, 128K fast SRAM and 256K Flash
  • 2 PWM, 4 high speed input & 4 high speed output channels
  • 39 digital IO and 8 Analog Inputs handle large applications
  • 2" x 2": fits in tight enclosures, smart sensors & actuators
  • BDM port for In Circuit Debug/Emulation to speed development
  • And many more features...

Mite v2 - fast, more affordable, tons of I/O

Ideal SBC for electric and internal combustion motor control, robotics, industrial automation, building control, data acquisition, instrumentation...

  • 16.1MHz Motorla 68HC16Z1, 128K LP SRAM and 128K Flash
  • 2 PWM, 4 high speed input & 4 high speed output channels
  • 39 digital IO and 8 Analog Inputs handle large applications
  • 2" x 2": fits in tight enclosures, smart sensors & actuators
  • BDM port for In Circuit Debug/Emulation to speed development
  • And many more features...

Intec News

STG and Intec Automation partner to deliver ZigBee solutions

Read more...

Intec announces ColdFire based Ethernet SBC

Read more...



Software

SBCTools-Std - Development Tool-Set for the ColdFire
SBCTools, Eclipse Edition

P&E ICDCFz Debugger/In-Circuit Emulator for the ColdFire
P&amp;E ICDCFz Debugger/In-Circuit


IPM Integrated Project Manager for the SS555
IPM Integrated Project
